Engine
-
- Type: 686cc, Water cooled, 5-valve, 4-stroke, 1-cylinder
- Bore x stroke: 102mm x 84mm
- Compression Ratio: 9:2:1
- Max. power: 25.0kw/5000-5500rpm, 33.5HP
- Max. torque: 49.0N.m/5000rpm
- Carbureation: PD42J
- Ignition: CDI
- Starting: Electric
- Transmission: L-H-N-R-P
- Drive Train: Axle
Chassis
- Suspension/Front: Independent double swing arm
- Suspension/Rear: Independent double swing arm
- Brakes/Front: Dual ventilated hydraulic disc
- Brakes/Rear: Triple ventilated hydraulic disc
- Tires/Front: Innova AT 25x8 - 12 radial
- Tires/Rear: Innova AT 25x10 - 12 radial
Dimensions
- LxWxH: 3010mm x 1460mm x 1840mm
- Seat Height: 790mm
- Wheelbase: 1890mm
- Ground Clearance: 245mm
- Fuel Capacity: 29L
- Dry Weight: 524kg
- Loading Quantity: 4pcs/20' GP; 9pcs/40' GP; 18pcs/40' HQ
Other
- Lighting: 12V35W/35Wx2, 12V5Wx2(front); 12V.5W/21Wx1 (rear)
Include
- Winch Mile Marker 3500
- Chrome wheels
- Roof
- Sundry Box
- Doors
Price: from $10,295.00 (including freight and PDI) + taxes
Financing Available
|
